Electrical Drive Flywheel - TDP 5 v2

The Electrical Drive Flywheel for the TDP 5 is the large cog on the left hand side of the press that attaches directly to the motor via the drive belt. It is unlikely that this will ever need replacing. However it is a good idea to check the teeth on yours regularly. If there are many missing teeth on the inside cog then it might be time to replace it.

Cast from iron and painted in an enamel red part is extremely durable.

This part has a grease nipple on it and it is very important to make sure that it is regularly greased. Not greasing it can cause it to heat up expand in its fitting and then jam. This puts extra strain on the motor and can cause it to burn out.

Before removing this part it is wise to turn off and unplug your machine as well as loosen the bolts on the Motor Support Arm to remove the tension from the V-Belt.

This part is fairly easy to fit. Firstly loosen of the motor by loosing the bolts on the motor support arm. Next remove the back cover to gain access to the nut that secures it. Undo the nut from the inside and the Drive Wheel will come lose.

As you refit your new part make sure that you do so using a couple of drive wheel mounting washers.

Maintenance and servicing the Drive Wheel for the TDP 5 just became a great deal simpler.

You will immediately discover why all of our parts are guaranteed as soon as your receive them. LFA has got the highest client retention rate within the industry. If you are having any problems with fitting this part please do not hesitate to get in contact with our team for help.

Imagine not having to have so much downtime on your production line. Problems can arise from things as small as missing teeth from the Drive Wheel for the TDP 5 or the wheel jamming up and locking in place.

You'll instantly be able to see the quality of our Drive Wheel for the TDP 5. Never fear extensive reductions in output again. With express delivery to almost anywhere in the world LFA give you the reassurance that you will be back on your feet soon.

Let LFA help your company perform more smoothly. These legitimate TDP parts are proven safe and effective by our own stringent quality control screening process.

All of our parts are brand-new and shipped rapidly to you. In addition all of these parts include a 180-day warranty, they also have a 100% full money back guarantee if you're not satisfied with our service. We offer free postage on our legitimate TDP parts.

Buy these high quality TDP parts today and you'll not be disappointed.
