TDP 1.5 Desktop Tablet Pers
De TDP 1.5 is een flexibel en eenvoudig te beheren tafelformaat pillenpers die een opmerkelijk niveau van output, prestaties en algemene flexibiliteit biedt. Hij kan draaien op zowel elektriciteit als handkracht, dit apparaat is de perfecte keuze voor iedereen die een hoogwaardige pers voor productie in kleine partijen en proefdraaien wil die geschikt is voor R & amp D of soortgelijke toepassingen.
Connect with Our Team
If you have a question or would like more details on the TDP 1.5 Desktop Tablet Pers, please complete the form below and someone from our team will be in touch with you soon.
Als u op zoek bent naar een tablet pers u om u te helpen nieuwe producten te produceren, of om concepten te testen voordat ze uitgerold worden voor de productie, biedt de TDP 1.5 de mogelijkheid om een reeks van tabletmaten in kleine volumes te maken, wat betekent dat dit apparaat zeker aan uw behoeften zal voldoen. Het is ontwikkeld om aan de eisen van laboratoria en ontwikkelingstaken te voldoen, in plaats van grootschalige productie, maar de TDP 1,5 is niettemin in staat om een hoeveelheid van slechts enkele tabletten tot een kleine batch tot 5000 tabletten per uur te produceren.
Het belangrijkste voordeel van deze tabletpers is gelegen in de veelzijdigheid, samen met de sterke functies en de hoogwaardige kwaliteit van de constructie. Dit laatste staat garant voor een uitstekende betrouwbaarheid. Om deze redenen is de TDP 1.5 een populaire optie voor gebruik in onderzoeksinstellingen, laboratoria, levensmiddellentechnologische toepassingen, farmaceutische ontwikkeling, chemische fabrieken en ziekenhuizen, of op locaties waar algemene flexibiliteit, eenvoud in gebruik en output erg belangrijk zijn.
Belangrijkste voordelen van de TDP 1.5
- Licht in zijn klasse
- Compacte footprint
- Snel en betrouwbaar
- Flexibele output
- Elektrisch of handmatig aangedreven
- Brede grondstoffen compatibiliteit
- Weinig onderhoud nodig
- Laag verbruik
- Werkt met 200g minimale hoeveelheid grondstoffen
- Perst tabletten in elke vorm
- Aanpasbare tablet diameter, diepte en hardheid
- Optie om dessins op de tablet te stempelen
- Passend voor verschillende soorten folie
Kenmerken van de TDP 1.5 Tabletteermachine
De TDP 1.5 is een single punch tabletteermachine, met een maximale druk van 15 kilonewton. Hij is gemaakt op een bank te worden geïnstalleerd, maar kan ook gemakkelijk worden verwijderd en verplaatst. De apparatuur heeft een instelbare vuldiepte met een maximale diepte van 12 mm, en kan tabletten produceren tot en 6 mm breed en 8mm dik. De TDP 1.5 beperkt u niet tot standaard gevormde producten. Door simpelweg de mal op het apparaat te wisselen kunt u gemakkelijk tabletten van bijna elke vorm die u kiest creëren. Bovendien kunt u de dichtheid van de pil veranderen, en het apparaat biedt de mogelijkheid om ontwerpen te stempelen op de bovenkant van de pil, voor een aantrekkelijke afwerking of identificatiedoeleinden. De TDP 1.5 is ook aantrekkelijk voor gebruik bij R & amp; D toepassingen, veel gebruikers vinden dit een nuttig aspect, omdat ze daarmee kleine hoeveelheden pillen met verschillende formules kunnen vervaardigen voor klinische studies.
De TDP 1.5 is ontworpen met gebruiksgemak in gedachten, hij staat bekend als een zeer functionele machine die elektrisch of in de handmatige modus aangedreven kan worden. In de handmatige modus wordt de pers aangedreven door het draaien aan een slingerwiel. In combinatie met een smalle basis en een laag gewicht voor een pers met deze specificaties, maakt deze veelzijdigheid de TDP 1,5 flexibeler en draagbaarder dan andere machines die gelijkwaardige prestaties bieden.
Technische Specificaties
De TDP 1.5 pers heeft afmetingen van 700 mm x 400 mm x 800 mm en weegt ongeveer 55 kilogram. Hij heeft een draaisnelheid van 1400 omw / min, als hij is aangedreven op elektrische energie, en de motor draait op een maximaal vermogen van 0,75 kW voor de fase oor eenmalig gebruik, en 0,55 kW voor gebruik in drie fases. Het apparaat werkt ook op netstroom die ofwel 110V of 220V levert.
TDP 1.5 Tablet Pers in Gebruik
Deze pers is opmerkelijk eenvoudig te gebruiken, en ondanks zijn compacte formaat levert hij een aantal voordelen die hem onderscheiden van vergelijkbare apparatuur.
Om de pers handmatig te draaien plaatst u de ruwe producten in de kegelvormige container, pak het wiel en draai het voorzichtig. Tablets verschijnen, klaar om te worden gebotteld. Het is een eenvoudig proces dat iedereen snel kan leren. Als u gewoon een paar pillen wil maken komt deze directheid pas echt tot zijn recht, het is ook een van de hoofdkenmerken van het apparaat. Als alternatief, als u een meer substantiële partij tabletten nodig heeft, kunt u de tabletteermachine gewoon op de netstroom aansluiten hij zal snel en efficiënt werken op elektrische stroom.
Het produceren en testen van producten vereist vaak de ontwikkeling van producten geformuleerd met vergelijkbare maar enigszins verschillende formuleringen. De TDP 1.5 bevat verschillende kenmerken die hem bijzonder geschikt maken voor dit doel.
In de eerste plaats is het een zeer efficiënte pers met een laag verbruik die het mogelijk maakt om meer pillen te halen uit een bepaalde hoeveelheid grondstoffen. Ten tweede, een specifiek voordeel van de 1.5 TDP is dat hij kan worden bediend een minimale hoeveelheid van slechts 200 g materiaal. Dit is echt ideaal voor onderzoek of educatie, als u slechts een paar tabletten wil drukken voor voorbereidende tests. Later, als u eenmaal veelbelovende formules heeft vastgesteld, kunt u de TDP 1.5 gebruiken voor grotere partijen voor volledige tests.
Als derde zorgt de TDP 1.5 dat u de effectiviteit van de testprocedure kunt beschermen, door ervoor te zorgen dat wat u produceert gemakkelijk kan worden herkend. Dit is belangrijk om ervoor te zorgen dat de juiste formule aan het juiste subject wordt aangeboden. De TDP 1.5 lost dit probleem op door het gemak waarmee u de vorm, grootte of het ontwerp van de tabletten kunt aanpassen. Als u een mal heeft voor het ontwerp dat u zou willen maken, kunt u de stijl snel wisselen door het losmaken van de hopper en het losdraaien van het feeder-mechanisme.
Het onderhoud van de TDP 1.5 is ook niet veeleisende, een tweemaandelijkse controle is voldoende, samen met het smeren en oliën van de belangrijkste bewegende componenten. De apparatuur is gebouwd om dit schema zo eenvoudig mogelijk te maken.
LFA's Visie
De TDP 1.5 vertegenwoordigt een uitzonderlijke waarde en biedt ongeëvenaarde flexibiliteit. Eenvoudig onderhoud en de keuze voor de productie van kleine series met de hand maakt dit een zeer geschikte machine, terwijl de mogelijkheid om te werken op elektriciteit en grote series van 5000 tabletten uur te produceren effectief twee apparaten in één biedt. Het is niet verwonderlijk dat de TDP 1.5 een van de meest favoriete machines in zijn klasse is.
| Naam | Waarde |
|---|---|
| Product | TDP-1.5 |
| Aantal ponsen | 1 |
| Max Druk (kN) | 15 |
| Max Diameter van Tablet (mm) | 8 |
| Max Vuldiepte (mm) | 12 |
| Max Tabletdikte (mm) | 6 |
| Max Productiecapaciteit Per Uur | 5400 |
| Aantal Vulstations | 1 |
| Dubbellaagse Tabletten | Nee |
| Motor (kW) | 0.55 |
| Aantal Fases | 1 |
| AMP | 13 |
| Volt | 240v (110v op aanvraag) |
| Hoogte (mm) | 800 |
| Breedte (mm) | 400 |
| Diepte (mm) | 700 |
| Gewicht (kg) | 53.5 |
| Net Weight (kg) | 53.5 |
How Much Profit Will This Machine Generate?
Are you able to calculate the amount of profit your business generates per tablet? If so, this calculator will be able to tell you how many hours you will have to run this tablet press to cover its investment.
It will also be able to tell you the amount of profit it will generate every hour you run this tablet press, which makes this calculator a powerful tool when deciding on which tablet press is right for you or your business.
Profit Generated Per Hour
This machine returns it's investment in hours
The advantage of the gearbox is that it has fewer open moving parts. This makes the press safer to use and easier to clean and maintain.
No. Both the hopper and the boot are made from brass or plastic depending on when you bought your machine from LFA. We moved to plastic in mid 2019.
The standard tooling is made from S7 steel, but can be customized using different steel grades.
The base plate is machined from stainless steel.
Yes. Some of them. There are a number of parts that are able to be changed between the different TDP ranges. This includes the tooling, a lot of the upper and lower drift pin assemblies and the boot bolt and spring.
No, the TDPs are not CE certified. To acquire this certification, they would have to be installed in a protective cage, which we do not provide.
Yes, there is a stop button. We would, however, also recommend installing the TDP 1.5 in a cage or perspex box.
Yes, you can, but there are a number of requirements that we need to fulfill first.
You will need to contact our team and provide them with a copy of all of your MSDSs for all of the components of your mix.
We need to have a good understanding of your business and the challenges you are facing.
You will also need to book an appointment with the office that you would like to visit.
For more information please get in contact with the team: https://www.lfatabletpresses.com/contact
Yes. Very easily.
We have free lifetime technical support for all machines sold by LFA.
Just contact us with your machine serial number and we would be happy to help you with any problems.
Yes, the contact surfaces are all food and pharmaceutical safe.
They are made from a combination of, stainless steel, chrome coated brass and the steel used for your tooling (often S7).
As such they are all compliant with most rules for food or pharma manufacturing.
We strongly recommend that you check your local laws as these do vary from state to state and country to country. If in doubt reach out, and we will be happy to find out.
Yes, you can.
You are able to make any shaped tablet up to the maximum diameter of this tablet press which can be found under the "specifications" tab.
We are able to customise tooling to include lettering, numbering and logos. If you would like customised tooling please fill out our custom tooling form: www.lfamachines.com/custom-tooling
Yes. You can order custom tooling here
No.
LFA does not recommend leaving any of its machines unattended without an operator ever. Even if they only need to step away for a short amount of time, the operator should turn off the machine.
This will avoid damaging it in the event that there is a jam and the operator is not there to switch it off.
Yes, the TDP and RTP range all have a weight adjustment for it.
on the TDP it is the bottom of the two cogs on the lower drift pin assembly.
Here is a link to a video showing you how to tune up the TDP 5: https://www.youtube.com/watch?v=4dTscUdRJzQ
Here is a link to a video showing you how to tune up the RTP 9 or the RTP 118: https://www.youtube.com/watch?v=YJFt5AFJ1hw
It is important to know that the exact weight of each tablet will vary from tablet to tablet.
A well-homogenized mix that has a consistent granule size should be able to achieve an accuracy of +/- 3% or less.
Yes, you could but they would be quite small. Most effervescent tablets are larger to accommodate the large amount of actives that they have to hold. The TDP 1.5 is only able to make a tablet up to 8mm in diameter, so we do not recommend it for anything larger than that, unless it has been tested first.
It is important to know two things:
Firstly, TDP Universal Tooling came into effect in 2018. Machines brought from LFA before this time may be slightly different sizes. We always recommend checking the size of your tooling before placing your order.
Secondly, a number of companies make unofficial TDP tablet presses.
They do not always conform to the same sizes, tolerance or quality as LFA TDPs or tooling. If you bought your press from someone else other than LFA, we are not able to guarantee that our tooling will fit.
Yes, you do get a die with the machine. Every machine comes fitted with a die.
If you would like you can get this customised with your logo or lettering but it takes 6-8 weeks.
Or, we have a standard 8mm round, bevelled edge with breaker installed in the machines in stock.
That depends on the country you are located in.
In the EU and UK no. You do not need anything to buy the press.
In the USA we have to file a piece of paperwork with the federal government when we sell the press.
We, however, do all of this paperwork for you and do not need to do anything.
The only countries that require a license, as far as we know, are Canada and Australia.
If you are located in Canada then we recommend that you contact Health Canada prior to placing your order. Details regarding the import process can be found at the following link: Importing and registering pill presses (designated devices)
The document you need to fill out and file for a purchase originating in Australia is called a B712. This can be found at: https://www.abf.gov.au/form-listing/forms/b712.pdf. If you would like to speak with one of our team about this, then please get in contact.
Yes, we do. Here is a link to a video that shows you how to set up your TDP 1.5 once you receive it: TDP 1.5 Unboxing & Setup
No, it does not need to be bolted into position but we do recommend it. If the machine is not secured in position by bolts or another method then it is more likely to shake a bolt loose, resulting in varying tablet weights. On top of this, the vibrations are likely to make the machine sound louder.
The machine does not come with bolts because we do not know the thickness of your surface.
The TDP 1.5 does not have a variable speed adjustment. It is possible to fit the press with a speed adjustment but it is not something that LFA offers as a service.
The TDP 1.5 is a little lighter than the TDP 5. It does not have a belt and exposed gears, but this does not affect its ability to make a tablet. The only thing it can not do is exert 50 kN of pressure.
We kunnen u trainen in Bicester, in onze vestiging. Het duurt ongeveer een dag.
The TDP 1.5 does not come with pressure load cells. It is not possible to fit them to the press.
The tooling on the TDP 1.5 is extremely durable. The life of your tooling, however, will depend on a number of things. This includes the shape of your tooling, the formulation of your mix, and the steel that the tooling is made from.
There are a number of questions to ask when determining the life of your tooling:
Does it have any chips or damage to the edge of the upper and lower punch? This section is called the land. If this is damaged it will show up in each tablet as a defect.
Do the tip faces of the punches have any cracks in them?
Is there a pitted look on the top or bottom punch face?
If you measure the working length of the upper and lower punches are they still within tolerance?
Is the upper or lower punch loose within the die bore?
Does the wall of the die bore have obvious scratches or scrapes on it?
Are you still clearly able to see the image, lettering, number or logo in the face of every tablet?
If your tooling shows any of these signs, then it could indicate that it is time to replace it.
Yes, it is almost completely the same as how you change the tooling on the TDP 5. The only difference is how you use the hand wheel to change the position of the machine so that you are able to complete the process.
Here is a link to how to change the tooling:How To Change A Die | Chaning a TDP Tablet Press Punch Die
The upper drift pin assembly is used to adjust the pressure. You can watch a video on this here: www.youtube.com/watch?v=pc2gfDU3NiQ
Here is another video which tells you how to set up a TDP ready to press: www.youtube.com/watch?v=4dTscUdRJzQ
There is a bolt eyelet on the top of the machine.
We recommend using an engine hoist to lift the machine off the shipping crate and into the position that you are going to use it in.
It takes about 1-2 hours to clean, disassemble, and grease a TDP 1.5. We recommend that this is done at the end of every run to ensure the maximum life of your machine.
We would recommend cleaning down the machine and leaving it re-greased after every use. This will ensure the longest life possible.
Here is a video on cleaning the TDP 5.
When greasing the machine, avoid getting any grease near the tooling or pressing surfaces, as this will get into your tablets and affect your powders.Grease the top cam well, then apply a small amount to the upper drift pin assembly and the lower timing rod.
More information on greasing your machine can be found here: TDP 5 Lubrication Schedule
Echt snel. De gemiddelde kosten per tablet wanneer ze door een contractfabrikant worden gemaakt, bedragen £0.002 - £0.005, afhankelijk van hoe moeilijk het is om ze te drukken en de grootte van de batch. Dat betekent dat een TDP 5 zichzelf terug zal betalen bij slechts 380.000 tabletten. Bij 5000 tabletten per uur is dat maar 76 uur.
The easiest thing to do is send LFA some of your product for us to test.
This is not a free service, we do charge for this but it could save you buying the wrong machine.
More information can be found on this service here: https://www.lfatabletpresses.com/services
This is a common question, and we have tools to help you:
A video on the differences between the different TDP's - www.lfatabletpresses.com/videos/tdp-range
The Right Machine For You Questionnaire - https://www.lfatabletpresses.com/tablet-press-questionnaire
These will explain the different machines, and give you a much better idea. If you are still unsure, please do reach out, let us know what you are making and the quantity, and we will help to guide you through the process.
Yes, you can make very strong tablets with 15kN. It will, however, depend on more than just the pressure. The size, shape, and formula will also determine the quality and strength of a tablet regardless of the machine. Increasing the pressure does not guarantee that your tablet will be stronger.
It might be possible, but it is not recommended.
The motor that is on the press has been carefully selected to match all of the other parts on the press. Switching the motor for a bigger or faster one could cause excessive pressure in other areas of the press resulting in machine damage.
If you think that you require a machine with more speed or higher pressure then we would recommend that you look into a TDP 5 or RTP rotary tablet press.
Apart from the tooling, we do not offer customizations on any of the LFA Tablet Presses. The TDP 1.5 has been designed with exact tolerances and forces in mind. Changing these might prevent your press from performing as intended.
Yes, the machine comes ready to plug in and go.
It is important to remember that the TDP 1.5 weighs 60 kg, so we recommend securing it to a benchtop. This should be done before running the machine for the first time.
You will also need to tune your TDP 1.5 before using it. We do not recommend just pouring in your mix and turning on the machine. Doing this will likely cause a jam and/or damage to the machine.
Yes, it can be, but as with all products it has to be tested. It is impossible to say if every herbal product will bind because it will depend on the total tablet mix and the shape and size of the tablet.
No. It is not they are completely different presses.
No, we do not offer a larger hopper for any of our presses. This is because the TDP 1.5 should not be left unattended at any time. This also prevents particle separation, where the larger particles in a mix rise to the top of the powder. The vibrations of the TDP 1.5 cause this to happen, but the hopper that is included has been designed to reduce the likelihood. If we were to attach a larger hopper then the chance of particle separation would dramatically increase.
In order to determine whether or not your machine is still under warranty, you will need to call or email the office the machine was purchased from, and provide the serial number.
The TDP 1.5 has an electric motor as well as a small hand wheel located on the top of the gearbox.
We always recommend tuning your press by hand before running it under power.
We do not recommend using the TDP 1.5 for long periods of time by hand. The function of the small wheel is to tune and de-jam the machine.
Yes, this could be down to corrosion or due to oxidation of your product. We would highly recommend taking your tooling out of the press and cleaning it at the end of every production run.
We would also recommend polishing the tooling to keep the surfaces clean and less likely to cause picking or capping.
Yes, this can happen because the boot bolt and spring have been screwed too far into the press or have not been screwed in far enough. It is important to make sure that the bolt is in the correct position before over tightening the set screw.
It should be pointed out that it will not affect the operation of the press if it is damaged.
The TDP 1.5 has a cast steel base with an enamel coating. There are parts that have been milled from steel and brass.
The contact parts that the powders come into contact with are the steel hopper, the brass/plastic boot (depending on model), the steel of the tooling (this will change depending on tooling specification) and the steel tablet ejection tray.
Dit is een veel voorkomende vraag als alle machines zijn zeer vergelijkbaar, maar even hebben verschillende sterktes.
De eenvoudigste manier om deze split-up zou worden in de automatische en handmatige machines.
De TDP 0 is de handleiding model en vraagt u om de hendel aan de zijkant voor het produceren van de tabletten. Dit heeft de minste hoeveelheid druk en is het entry-level model in de TDP bereik.
De TDP 1.5, TDP 5 en TDP 6s zijn alle automatische machines die worden aangedreven door een elektrische motor. De TDP 1.5 is het entry-level model in de automatische machines het heeft de minste druk op 15kn het is ook beperkt in de omvang van de tabletten kan produceren. De TDP 5 is ons meest populaire model en kan produceren ongeveer 5.000 tabletten per uur. De TDP 5 had 50kn van druk en kan het produceren van tablets tot 22mm diameter. De TDP 6s is de bovenkant van het bereik van de machine en is meer geschikt voor een onregelmatige vorm van tabletten. De TDP 6s heeft ook iets meer druk op 60kn en is beter geschikt voor bepaalde producten die niet in de vorm van tabletten zo gemakkelijk.
The length of the warranty on any of the TDP range machines is 1 year from the date of purchase.
This warranty covers spare parts and excludes tooling and maintenance labour from LFA for machine services.
When you receive your machine, you will be given a serial number that will also be stamped onto the press. You will be able to use this if you ever need to make a warranty claim.
Full details on the LFA warranty can be found here: Warranty | We Have You Covered
De TDP 5. Dit is al een tijdje het meest populaire model. We hebben klanten die terugkomen en upgraden naar de RTP 9 (meestal na een paar jaar), maar de meeste klanten beginnen met de TDP 5.
The TDP 1.5 is recommended for any tablets that are smaller than 8 mm and bind fairly well, rather than for a specific type of tablet or product. If you are unsure, then it is best to have the product tested. More information can be found on this service here: Services | Why Choose LFA Tablet Presses
As with any tablet press, it is good to have a particle size of around 80-60 mesh.
This would be large enough to avoid large losses and small enough to flow well through the machine. If the powder is finer than this then you are going to experience a larger level of loss.
If the particles are larger than this then it might not flow through the machine well and get caught as it is trying to enter into the die bore.
This being said every powder is very different and you will need to do tries to work out what is best for them.
We send out all machines with the local plug on and set up to run on the local power supply.
We would recommend using goggles, a dust mask and gloves at a minimum, but you may require a lot more depending on the products that you are working with, and your local health and safety laws.
It depends on how close you are to forming a tablet with the TDP 1.5. If the tablet binds but gets chipped or damaged during ejection, or falls apart when inside a container, then moving to a TDP 5 or 6 might give you the extra force you need to make your tablet work.
If however, your tablet comes out of the TDP 1.5 as dust, then it is unlikely that the problem you are facing has to do with the amount of pressure that you are applying.
Get a capsule filler.
You will not be able to make tablets.
Click here for more information https://www.lfacapsulefillers.com/
There are a number of ways we are able to support you:
- Every machine comes with a full manual that is emailed to you after purchase.
- There is a large range of video tutorials to teach you how to use the press.
- The machine comes with lifetime technical support. You can call, Skype or email to get answers to your questions and problems.
- We also offer free training at any one of our regional offices.
If after all of this you are still struggling to use your press, we are able to come to you. This is a service we charge for.
More information on this can be found here: https://www.lfatabletpresses.com/services
All of our machines are made by us in Taiwan, and are shipped to you from our nearest office.
We have offices in the UK, USA, Germany and Taiwan.
Because they are made by us, we are able to control quality and give you the best support possible. And because they are shipped from your local office, wait times are reduced and customs clearance is avoided, ensuring you have support in your time zone in a language that is convenient to you.
The most common part to wear out on the machine is the boot. This comes in direct contact with the die cavity and can be hit or chipped by the upper and lower punches. This is made of brass so that the tooling is protected in the event of a collision. Because of this, the boot is soft and will wear over time. If anything, we recommend keeping a spare to avoid losing production time.
We also recommend that you keep at least 1 spare set of tooling as this can break or wear over time.
LFA aims to hold all major spare parts and tooling in stock so that they are ready to ship out in the event that you need them. The lead times on sold out parts, however, can take up to 6-8 weeks
There are a few interchangeable parts if both machines have been made by LFA Machines. From the TDP 0, this includes the tooling, the lower drift pin assembly, and its corresponding set of cogs.
The most important fit to check for is tooling that you may have previously purchased, because the base plates have been redesigned to fit the universal standard tooling die.
More information on the TDP Universal Tooling Standard can be found here: Tooling | Punch & Dies for TDP Pill Presses
All other parts are custom to this press.
Yes, some parts are interchangeable if both machines have been made by LFA Machines. The upper drift pin assembly and the lower drift pin assembly will fit.
The most important fit to check for is tooling that you may have previously purchased, because the base plates have been redesigned to fit the universal standard tooling die.
More information on the TDP Universal Tooling Standard can be found here: Tooling | Punch & Dies for TDP Pill Presses
There are three reasons to granulate your formula:
1. To improve the flowability of your formulation.
2. To make your formulation more compressible.
3. To ensure a consistent spread of API throughout the formulation.
If you would like to find out if your mix needs granulation then we do have a tablet formulation service available.
You can find out more about the tablet formulation service here: https://www.lfatabletpresses.com/services
